120ton cua txias txias ntsia hlau chiller tsev
| Qauv | HWAL420 | ||
| Nominalcoolingcapacity | kW | 415 | |
| Cua Txias Zog | kW | 133 | |
| Lub hwj chim muab | 380V / 3PH / 50Hz | ||
| Cov Tswj Hluav Taws Xob | Lus Askiv tso saib lub vijtsam, kuaj xyuas qhov chaw / lub sijhawm, keeb kwm kev nug, kev ceeb toom yuam kev, thiab lwm yam | ||
| Ntsuas Dej | Hom | Semi-hermetic ntsia hlau compressor | |
| Lub Hom | hanbell | ||
| Kom muaj nuj nqis | chav nyob | 2 | |
| Lub zog hluav taws xob | 0-25%-50%-75%-100% | ||
| Tub yees | Hom | R134a | |
| Tshuab looj | Hom | Aluminium fins nrog tooj liab tub luam | |
| Condenserfan | Hom | Axialfan | |
| Kom muaj nuj nqis | chav nyob | 1.8*8 | |
| Tsho dej heatexchanger | Hom | Shellandtube | |
| Chilledwaterflow | m3/h | 75 | |
| Connectionpipe | hli | DN125 | |
| Dej Tawm Tsam | kPa | 50 | |
| Chav Haujlwm | Ntev | hli | 4800 |
| Dav | hli | 2150 | |
| Qhov siab | hli | 2200 | |
| Lub cev hnyav | kg | 5000 | |
| Qhuas | dB (A) | 83 | |
