Khoom nta:

1.Seawater Cooled Packaged Marine Air Conditioner yog siab ESP, los yog customized tsim.

2. Seawater Cooled Packaged Marine Air Conditioner yog tus qauv tsim los tiv thaiv thermal rwb thaiv tsev zoo tshaj plaws, qhov tsawg kawg nkaus lub zog poob.

3. Seawater Cooled Packaged Marine Air Conditioner yog thermal expansion valve kom paub tseeb tias qhov ua tau zoo tshaj plaws ntawm qhov ntsuas kub tsis sib xws.

4. Anti-corrosive Cupronickel kauj lossis Titanium dej kauj.

Technical specification:

Sea-water cooled Package Unit (Dej-Air)
Qauv NO.	MWL
Lub peev xwm txias	kW	19-258
Fais fab mov		220V ~ 380V / 3PH / 50-60Hz
Cov ntaub ntawv kiv cua	Cua ntws	m³/h	1600~38500
Sab nraud static siab	Pa	80-850
Lub suab nrov	dB (A)	50~73
Lub cev muaj zog	kW	0.3~22
Cov tub yees	Hom	R22/R407c/R410a
Compressor	Hom	Hom	Hermetic Scroll
Rated zog	kW	2.25~66
Water side heat exchanger	Hom	Hom	Alpaka& SS316 Tube phaj& kawg lub plhaub thiab lub raj
Dej ntws	m³/h	2.3~42
Dej siab poob	mH₂O	2.3~6.3
Cov yeeb nkab txuas	hauv / mm	DN25/32/40/50/65
Cua sab cua kub exchanger	Hom	Copper tubes nrog txhuas fins los yog tooj liab fins
Chav Dimensions	LWH	mm	750x550x1600~3500x1700x2000
Nco tseg:
1. Nominal txias txias: sab hauv tsev cua kub 27 ℃ DB / 19.5 ℃ WB; dej hiav txwv inlet / qhov hluav taws xob kub 32 ℃ / 37 ℃.
