Khoom nta:

1.Sea Water-cooled Cooling Scroll Air Conditioneradopts qhov tseeb hloov tau yooj yim scroll compressor. Piv nrog rau piston hom compressor, scroll compressor boasts siab piv ntawm lub zog rau efficiency, siab ntseeg siab thiab tsis muaj suab nrov.

2.Sea Water-cooled Cooling Scroll Air Conditioneradopts finned thav duab stainless hlau hluav taws xob rhaub uas yog featured los ntawm cov hluav taws xob loj cheeb tsam, siab kub efficiency thiab ntev kev pab cuam lub neej. Tsis tas li ntawd, nws tau muab nrog lub ntsuas kub tiv thaiv uas ua kom muaj kev nyab xeeb thiab kev ntseeg siab ntawm chav tsev.

3.Sea Water-cooled Cooling Scroll Air Conditioner txais ob peb lub tub yees ywj siab, uas tuaj yeem pab txhawb kev hloov kho lub zog thiab txuag hluav taws xob ntau dua.

Khoom nta:

Sea-water cooled Package Unit (Dej-Air)
Qauv NO.	MWL
Lub peev xwm txias	kW	19-258
Fais fab mov		220V ~ 380V / 3PH / 50-60Hz
Cov ntaub ntawv kiv cua	Cua ntws	m³/h	1600~38500
Sab nraud static siab	Pa	80-850
Lub suab nrov	dB (A)	50~73
Lub cev muaj zog	kW	0.3~22
Cov tub yees	Hom	R22/R407c/R410a
Compressor	Hom	Hom	Hermetic Scroll
Rated zog	kW	2.25~66
Water side heat exchanger	Hom	Hom	Alpaka& SS316 Tube phaj& kawg lub plhaub thiab lub raj
Dej ntws	m³/h	2.3~42
Dej siab poob	mH₂O	2.3~6.3
Cov yeeb nkab txuas	hauv / mm	DN25/32/40/50/65
Cua sab cua kub exchanger	Hom	Copper tubes nrog txhuas fins los yog tooj liab fins
Chav Dimensions	LWH	mm	750x550x1600~3500x1700x2000
Nco tseg:
1. Nominal txias txias: sab hauv tsev cua kub 27 ℃ DB / 19.5 ℃ WB; dej hiav txwv inlet / qhov hluav taws xob kub 32 ℃ / 37 ℃.
