Khoom nta:
1.Marine nkoj cua txias nrog compact tsim thiab lub teeb yuag. Yooj yim rau qhov chaw nrog qhov siab qis.
2.Marine nkoj cua txias yog rov qab lub voj voog qauv nruab nrog cua txias thiab cua sov.
3.Compressor nrog kev ua haujlwm ntawm kev ua haujlwm siab, kev vibration qis thiab kev siv hluav taws xob tsawg
4.Condensers coil nrog high-efficiency kauv ob lub raj tso cai rau kev sib pauv kub kub
5.Marine nkoj cua txias yog ywj siab kho qhov hluav taws xob
6.Rust resistant Cheebtsam los ntawm kev siv stainless, aluminium thiab ABS yas
7. Kev sau tshiab ntawm cov dej ntws txo qis tshaj qhov dej ntws los ntawm cov dej ntws tawm
8. Smoother ntws yog muaj los ntawm kev tso qhov chaw zoo tshaj plaws ntawm kev teeb tsa
Khoom piav qhia:
Sea-water cooled Package Unit (Dej-Air) | |||
Qauv NO. | MWL | ||
Lub peev xwm txias | kW | 19-258 | |
Fais fab mov | 220V ~ 380V / 3PH / 50-60Hz | ||
Cov ntaub ntawv kiv cua | Cua ntws | m3/h | 1600~38500 |
Sab nraud static siab | Pa | 80-850 | |
Lub suab nrov | dB (A) | 50~73 | |
Lub cev muaj zog | kW | 0.3~22 | |
Cov tub yees | Hom | R22/R407c/R410a | |
Compressor | Hom | Hom | Hermetic Scroll |
Rated zog | kW | 2.25~66 | |
Water side heat exchanger | Hom | Hom | Alpaka& SS316 Tube phaj& kawg lub plhaub thiab lub raj |
Dej ntws | m3/h | 2.3~42 | |
Dej siab poob | mH2O | 2.3~6.3 | |
Cov yeeb nkab txuas | hauv / mm | DN25/32/40/50/65 | |
Cua sab cua kub exchanger | Hom | Copper tubes nrog txhuas fins los yog tooj liab fins | |
Chav Dimensions | L*W*H | mm | 750x550x1600~3500x1700x2000 |
Nco tseg: | |||
1. Nominal txias txias: sab hauv tsev cua kub 27 ℃ DB / 19.5 ℃ WB; dej hiav txwv inlet / qhov hluav taws xob kub 32 ℃ / 37 ℃. | |||
FAQ:
Q1: Koj lub tuam txhab' yog dab tsi; qhov kev pab cuam tom qab muag?
A1: Peb lub sijhawm lav yog ib xyoos. Yog tias muaj teeb meem hauv lub xyoo no, peb tuaj yeem xa cov khoom tshiab rau koj los hloov. Lub caij no, zoo siab txais tos rau kev sab laj kev paub txog kev paub.
Q2: Nws puas tuaj yeem ua peb lub logo ntawm cov khoom?
A2: Yog lawm, OEM muaj, suav nrog cov qauv tshwj xeeb, xim, logo, ntim thiab lwm yam.
Q3: Koj puas tuaj yeem tsim raws li cov qauv?
A3: Yog lawm, peb tuaj yeem tsim los ntawm koj cov qauv lossis cov duab kos duab.
Q4: Yuav ua li cas txog lub sijhawm khoom xa tuaj?
A4: Txog 25-30 hnub tom qab tau txais qhov tso nyiaj thiab kev pom zoo ntawm txhua tus qauv tsim raws li qhov xwm txheej ib txwm muaj.
Cim npe nrov: Marine nkoj cua txias, Tuam Tshoj, manufacturers, customized, quotation, luv nqi, ua nyob rau hauv Suav teb
